Here is a brief summary of the transcript: The transcript describes the process of assembling a Honda D15 engine and explaining each part. It goes through the six main systems that make up the engine: - Rotating assembly - Includes parts like pistons, connecting rods, crankshaft, seals, oil pump, etc. These parts allow the engine to convert the up and down motion of the pistons into rotational motion. - Timing - The camshaft, timing belt, gears, etc synchronize the motion of the valves with the motion of the pistons for proper combustion timing. - Cooling - Water pump, thermostat, radiator, hoses circulate coolant to prevent the engine from overheating. - Airflow - Air filter, throttle body, intake and exhaust manifolds control the air and fuel mixture for combustion. - Electrical - Sensors provide input to the ECU which controls ignition timing and fuel injection. Alternator charges the battery. - Fuel - Fuel pump, injectors, fuel rail, pressure regulator deliver the proper amount of fuel for combustion. Key points: - Many intricate parts working together allow the engine to convert fuel into rotational mechanical power. - Proper timing of the valves, ignition, and fuel injection is critical. - Cooling and lubrication are vital for the engine's operation and longevity.

Speaker A: This is a fuel injector. It sprays gasoline into your engine. And it's just one out of 94 parts that make up an engine. Well, more specifically, that make up the Honda D 15 engine. In this video, we're going to assemble a D 15, and along the way, explain each and every individual part that goes into it, from the obvious, like the pistons, to the slightly more obscure, the valve spring retainers. Do you know every single part that goes into an engine? Well, you're about to. Let's start with the basics. A piston is attached to connecting rod via a wrist pin. On the bottom of the connecting rod is a crankshaft bearing. This minimizes wear and allows the connecting rod to rotate smoothly when attached to the crankshaft, a rod cap holds the other end of the connecting rod onto the crankshaft, completing the connection. Now, as the piston moves down the inside of a cylinder, it draws in an air fuel mixture. The piston compresses that mixture, which is then ignited by a spark plug. The resulting combustion pushes the piston back down. And then as it returns the top, it pushes out exhausted exhaust gases. And the cycle continues sucking in air and fuel, compressing it, igniting it, and then pushing out the exhaust. Now, that process is what gets the crankshaft spinning, which spins the transmission, which spins the drive shaft, which spins your wheels. Okay, so, that's the basics out of the way. But to cover each and every part that goes into this engine, we're gonna have to break it down into six systems. The rotating assembly, that's the central mechanical system at work. Timing. A lot is going on inside. Inside an engine. And those moving pieces need to work in unison. Cooling engines want to get hot, so you need a system to keep them from overheating airflow. If you want to burn fuel, you need oxygen in the equation. Electrical. Whether it's a modern car or a 50 year old beater, a functioning engine needs a functioning electrical system. And finally, and maybe most obviously, fueling. Okay, so, in order for compression and combustion to take place, we need a strong, sealed combustion chamber. That is our engine block, and it forms the cylindrical walls of the chamber, while piston rings mounted on the outside of the piston ensure a tight seal. Now, in our case, the top two rings are called compression rings, and they form a seal between the piston and the cylinder wall, while the third ring, called an oil control ring, distributes a thin layer of oil on the cylinder so the piston can move smoothly up and down. Now, inside the block are various coolant and oil passages, called galleries, to help keep the engine cool and lubricated. Looking at the engine block upside down, you can see the semi circular cutouts that will house the crankshaft, which are fitted with crankshaft bearings and two thrust bearings that prevent the crankshaft from sliding back and forth. Okay, good job, boys. That's pretty cool. Now, we have a quick word from our sponsor today, which is mothers. But you guys can work on getting the pistons put in while I go to the little boys room, okay? I gotta take a leak. Bad timing.

Speaker B: What's that?

Speaker C: Oh, it's the odor eliminator and refresher from today's sponsor, mother's polish. It'll destroy 99% percent of odors from your car. Talking mildew, pet smells, old food, anything, really.

Speaker B: How's it work?

Speaker C: Start the car, close the windows, turn the ac to max cold, set the fan to high, and make sure recirculate is on. Give the can a good shake, put it in the cup holder, press the locking lever, and get out. In just 15 minutes, it'll smell like a brand new car.

Speaker B: Yeah, but how does it really work?

Speaker A: Hmm.

Speaker C: Melody, 09:00 focus all power on the vents. I love the smell of new car in the morning.

Speaker B: Just hang on. The mission's almost over.

Speaker C: I did good, didn't I?

Speaker B: You deodorized. The hell, Adam. Soldier.

Speaker C: No, you know, I have no idea. It just does. In the fight against car stink, mother's odor eliminator and refresher stands victorious. Click the link below to get your car back to freshen.

Speaker A: Okay, looking good, boys. All right, now let's pick up the pace a little bit. Holding the crankshaft is a crankshaft support bracket, which uses little Preston dowel pins to stay perfectly aligned. A rear main seal inside the rear main seal housing keeps oil from leaking out of the back of the engine. If you own a car from the nineties, this is leaking right now in your driveway. Go check it out. I'll wait. I'll wait. See, I told you. Now, the front main seal is actually situated in the oil pump. And the oil pump is directly powered by the crankshaft. As it spins, the oil is forced through the galleries, constantly lubricating all of the engine's components. It is also sent through the oil filter, which catches any contaminants in the oil before getting to those important components. Now, feeding the oil pump is the oil pickup tube, which draws oil from the oil pan, which is kept sealed with the oil pan gasket. Now, the oil pan is oftentimes called the oil sump, and it's where you'll find the oil drain plug, which lets you drain oil before you do a change. This thing right here. Drive through oil shops hate these things. Okay, let's flip the engine over to get ourselves the proper perspective. Because the engine is translating the up and down motion of the pistons into a rotational motion. That rotational motion of the engine, it can get a little jerky. So a flywheel is attached to the back of the crankshaft to help smooth out some of the engine's rotational motion. The flywheel is cast with teeth along the outside of it. And those hook up with the starter motor. That's just a small electric motor that gets the engine spinning before combustion can take over. All right, so that covers most of the rotating assembly, but a lot of the action in the engine occurs at the top of the combustion chamber in the engine's head. Now, this mounts on top of the engine block with the head gasket, ensuring you got a tight seal. Not only does the head seal off the top of the combustion chamber, it also houses all of the intricate pieces that control airflow. Yeah, a lot of pieces. That includes things like the intake and exhaust valves, which let fresh air into the combustion chamber and lets waste gases out. The valves are held closed by valve springs, which are held in place with valve spring retainers. The valves are pushed open using the camshaft. In our engine, we just have a single camshaft controlling both intake and exhaust. But other engines could have up to four camshafts. And the camshaft is made up of offset lobes. So, as the camshaft spins, which is inside the camshaft bearings, those lobes push on rocker arms, which pivot on a rocker arm shaft, and push on the valve. The valve runs through a valve stem seal to keep that oil lubricating this whole assembly and keep it inside the combustion chamber. So, as we spin the camshaft, you can see how the lobes push against the valve assembly, and the valves open and they close. Now, when assembled, the entire valve assembly looks like this. Okay, cool. Now, let's put the head on the engine. But where did the engine go, really? Oh, good job. Good thinking. Now, let's get that head on. Okay, so, we want to make sure that air is going into the engine at the right time and exhaust is leaving the engine at the right time. You wouldn't want a valve opening in the middle of a combustion stroke. So, in order to synchronize the timing of the valves to match the timing of the pistons, we can just synchronize the rotation of the camshaft with the rotation of the crankshaft. So, to do that we need a few gears and a timing belt. A cam gear is mounted to the end of the camshaft to time the cams. And a crankshaft gear is mounted to the end of the crankshaft to drive the camshaft. But the timing belt doesn't just turn the cam gear. It also powers the water pump, which is responsible for sending coolant throughout the engine block to prevent it from overheating. And we're going to come back to cooling in just a minute. But first, we need to keep tension in the timing belt. Using a timing belt tensioner. And the way we link our cam gear, our crankshaft gear, and our water pump gear together so that everything is in time is by using a timing belt now, to prevent any dust or other things, debris getting into those planes, we need a timing belt cover. And then, on top of our precious valve assembly, is protected by a valve cover. Now that the valves controlling our air intake and exhaust are in time. And the motion of the pistons is in time, we need to ensure that the combustions happen in time as well. So, like we mentioned earlier, each combustion is set off by a spark plug. Now, unfortunately, the 12 volts from a car battery isn't sufficient for a spark plug to create an arc. So an ignition coil uses induction to increase the voltage from 12 volts to something like 40,000 volts. In our case, the ignition coil is found inside a distributor, which makes sure each spark plug fires at the correct time via the rotor. The end of the rotor receives electrical current from the ignition coil. So as the camshaft spins, the rotor spins. And it comes in and out of contact with four terminals in the distributor. Captain, as it touches those terminals, an electric current is sent to a corresponding spark plug via a spark plug wire. And that is what sparks and ignites our air fuel mixture to create combustion. Now, with all those sparks going off thousands of times a minute, we need to keep the battery charged with an alternator. Now, the alternator is held in place by an alternator bracket and an alternator tensioner inside the alternator. That is where all the magic is happening. An electric current is induced by spinning an electromagnet. That electromagnet is spun by the alternator pulley. Now, driving that pulley is a harmonic balancer. Sometimes this would just be a crankshaft pulley. But our pulley is integrated into the balancer, which helps dampen vibrations in that rotating assembly. And the way we get the alternator pulley spinning is by means of an alternator belt. Now, with all those little explosions going off every second. Engines, they can get hot, like really hot. And since the crankshaft is always spinning, the water pump will always be spinning as well. But sometimes, like in cold weather, you actually want the engine to warm up a bit. So this coolant pipe exiting the pump leads to a thermostat housing, which houses the thermostat. So the thermostat is technically a valve that slowly opens and closes, depending on the coolant's temperature. When the coolant's cold, the thermostat closes, and the coolant is redirected back to the engine to keep warming up. As the coolant heats up, the thermostat opens, directing the coolant out of coolant hoses, making its way to the front of the car, where it enters the radiator. And attached to the radiator is a cooling fan, which helps dissipate the heat into the air before the coolant returns back to the engine. Now, throughout this process, as coolant heats up, it expands. So the radiator cap allows that expansion to happen at a set pressure. If the pressure gets too much, a spring in the cap compresses where coolant will flow over into the coolant reservoir. Now, for an engine to run properly, the ratio of air to fuel and combustion chamber is absolutely critical. So we need control the airflow going into the engine's intake ports right here. Now, starting from outside the car, air goes through the air filter, which is in the air filter housing. Now, this gets rid of any major contaminants before going through the air intake pipe and past the throttle body. Now, the throttle body houses a butterfly valve that is controlled by the gas pedal, and it determines how much air gets into the engine. The more air, the more fuel, the faster you can go. The throttle body connects to the intake manifold, which splits apart into four runners, one for each cylinder in the engine. Next to the throttle body is the idle air control valve. It's a little bypass valve that can allow more or less air to flow into the intake manifold to compensate for different air temperatures and densities, and that helps maintain a smooth idle speed. Now, after combustion, the exhaust gases from each cylinder converge into an exhaust manifold, and then they go through a front pipe into a catalytic converter, a freaking thieves favorite part of a car where a chemical reaction converts really bad emissions into only kind of bad emissions. That exhaust gas flows through your exhaust pipe, reaching the muffler, which quiets everything down, and then finally out the tailpipe. Now, some of the combustion might actually get past the piston rings and into the crankcase below. And in that case, the gases will be routed through the pcv system, which stands for positive crankcase ventilation. This includes an oil separator, which is just a box with baffles to ensure only the blow by gases escape. A pcv valve, which is just a one way valve, and a hose that leads back to the intake manifold. That way, any potential harmful fumes will have a chance to get burned up during combustion. Okay, so where are we at? We covered rotating assembly, timing, cooling, airflow. There are just two main pieces left in this puzzle. Next up, we need to talk about the brains of the car, the electrical control unit, or ECU. So, the ECU manages nearly all of the electrical functions in your car. It also processes signals from various sensors to optimize engine performance. Some sensors are just position sensors that tell the ECU the timing of everything, like the crankshaft position sensor, the cylinder position sensor, and the throttle position sensor. Other sensors let the ECU know information about the elements moving through the engine, like the coolant temperature sensor, the intake air temperature sensor, and the o two sensor that lets the ECU know how much unburnt oxygen is in the exhaust. The manifold absolute pressure sensor, or map, lets the ECU know how much air is getting to the cylinder. And all of those sensors are linked together by the wiring harness. Okay, we're almost there. We cover the rotating assembly, the timing system, the intake and exhaust, the electrical, the cooling, and the lubrication systems. The only thing missing from our engine is the fueling. As you can guess, the fuel starts in the fuel tank, gets sucked up by the fuel pump, which includes a fuel filter to keep out some of the larger contaminants. And that pump sends it down fuel lines until it hits the fuel rail. At the end of the fuel rail is a fuel pressure regulator to maintain the correct fuel pressure with any excess being sent back to the tank via the fuel return line. The fuel you want, it goes through the injector, spraying fuel into the combustion chamber so that your engine can run. And that is every. We're missing in an injector. Here you go. And that is every single part of an engine explained in 14 minutes and 37 seconds. Thank you guys so much for watching this and everything else at donut. We'll see you next time. All right.
